Swivel Flow Control Valve

Get a Price/Quote

MOQ : 50 Pieces

Swivel Flow Control Valve Specification

Finish
Corrosion Resistant Coating

Application
Hydraulic, Pneumatic, and Water Systems

Control Mechanism
Manual/Actuated

Seal Type
Nitrile Rubber (NBR)

Flow Range
0.2 to 80 L/min

Weight
Approx. 480 g

Swivel Angle
360° Rotation

Mounting Orientation
Horizontal/Vertical

Swivel Flow Control Valve Trade Information

Minimum Order Quantity
50 Pieces

Delivery Time
2 Week

Main Export Market(s)
Central America, Asia, Australia, North America, South America, Eastern Europe, Middle East, Africa, Western Europe

Main Domestic Market
All India

About Swivel Flow Control Valve

Swivel Flow Control Valves find applicability in petroleum-based fuel dispensing. These are needed to control air flow and are functional as the single-acting as well as double-acting cylinders. Offered valves are utilized to make control over the air flow in many directions. Swivel Flow Control Valves can work well with a cross-sectional flow. Offered are the space-saving valves, which can work without the help of accessories. They can be fitted with ease and less exertion.

Features:

Rugged design
Excellent flow regulation
Precise dimension
Corrosion resistance

Working Pressure: 0.1 TO 10 BAR.

Working Temperature: -10 to 60o C.

Availability of Size

1) SFCV1/8-04               1/8 BSP MALE X 4MM TUBE
2) SFCV1/8-06               1/8 BSP MALE X 6MM TUBE
3) SFCV1/8-08               1/8 BSP MALE X 8MM TUBE
4) SFCV1/4-06               1/4 BSP MALE X 6MM TUBE
5) SFCV1/4-08               1/4 BSP MALE X 8MM TUBE
6) SFCV1/8-1/8              1/8 BSP MALE X 1/8 BSP FEMALE
7) SFCV1/4-1/4              1/4 BSP MALE X 1/4 BSP FEMALE
8) SFCV3/8-3/8              3/8 BSP MALE X 3/8 BSP FEMALE
9) SFCV1/2-1/2              1/2 BSP MALE X 3/8 BSP FEMALE.
