Stainless Steel Double Ferrule Male Pipe Weld Connector

Price 35 INR/ Unit

Get a Price/Quote

MOQ : 10 Units

Stainless Steel Double Ferrule Male Pipe Weld Connector Specification

Product Type
Double Ferrule Male Pipe Weld Connector

Material
Stainless Steel

Type
Male Pipe Weld Connector

Shape
Straight

Technique
Cold Forming and CNC Machining

Surface Treatment
Polished / Passivated / Electrolytic

Standard
ASTM A276 / ASTM A182

Outer Diameter
1/8 to 2 (3 mm to 50 mm) or as specified

Length
Custom lengths available

Inside Diameter
Customizable as per requirement

Wall Thickness
As per standard or customized

Tensile Strength
515 MPa minimum (for SS 316)

Grade
SS 304 / SS 316 / SS 316L

Size
1/8 to 2 NPT / BSPT / BSP / Metric Threads

Color
Metallic Silver

Stainless Steel Double Ferrule Male Pipe Weld Connector Trade Information

Minimum Order Quantity
10 Units

Supply Ability
100 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Stainless Steel Double Ferrule Male Pipe Weld Connector

Stainless Steel Double Ferrule Male Pipe Weld Connector

We have marked a remarkable position in the industry by manufacturing, exporting and supplying a broad array of Male Pipe Weld Connector. This connector is efficiently manufactured by utilizing optimal grade metal alloy with the help of advanced technology under the stern observation of our experts. Offered connector is used for pipe and tube fitting applications in various industries. In addition, this Male Pipe Weld Connector can be availed from us in numerous sizes at industry leading price.

Features:

Robust built
Resistant to corrosion
Dimensional accuracy
High strength

METRIC

Part No.	Tube O.D. T mm	Pipe Weld Size P mm	E mm	h mm	H mm	F	G	l1
PMWC-M03-02	3	1/8	2.4	12	12	12.9	15.3	9.7
PMWC-M04-02	4	1/8	2.4	12	12	13.7	16.1	9.7
PMWC-M06-02	6	1/8	4.8	14	14	15.3	17.7	9.7
PMWC-M06-04	6	1/4	4.8	14	14	15.3	17.7	14.2
PMWC-M08-02	8	1/8	5.1	15	16	16.2	18.6	9.7
PMWC-M08-04	8	1/4	6.4	15	16	16.2	18.6	14.2
PMWC-M08-08	8	1/2	6.4	22	16	16.2	18.6	19
PMWC-M10-04	10	1/4	7.1	18	19	17.2	19.5	14.2
PMWC-M10-06	10	3/8	7.9	18	19	17.2	19.5	14.2
PMWC-M10-08	10	1/2	7.9	22	19	17.2	19.5	19
PMWC-M12-04	12	1/4	7.1	22	22	22.8	22	14.2
PMWC-M12-06	12	3/8	9.5	22	22	22.8	22	14.2
PMWC-M12-08	12	1/2	9.5	24	22	22.8	22	19
PMWC-M15-08	15	1/2	11.9	24	25	24.4	22	19
PMWC-M16-08	16	1/2	12.7	24	25	24.4	22	19
PMWC-M18-08	18	1/2	13.5	27	30	24.4	22	19

TOP IMPERIAL

Part No.	Tube O.D. T	Pipe Weld Size P		E Min	h	H	F	l	L
Part No.	in	Nom	O.D.	E Min	in	in	F	l	L
PMWC-02-02	1/8	1/8	10.3	2.28	7/16	7/16	12.7	23.87	31.24
PMWC-03-02	3/16	1/8	10.3	3.04	7/16	1/2	13.71	24.63	31.24
PMWC-04-02	1/4	1/8	10.3	4.82	1/2	9/16	15.24	25.4	32.76
PMWC-04-04	1/4	1/4	13.7	4.82	9/16	9/16	15.24	30.48	37.84
PMWC-05-02	5/16	1/8	10.3	5.08	9/16	5/8	16.25	26.67	37.03
PMWC-05-04	5/16	1/4	13.7	6.35	9/16	5/8	16.25	31.24	38.6
PMWC-06-04	3/8	1/4	13.7	7.11	5/8	11/16	16.76	32.51	39.87
PMWC-06-06	3/8	3/8	17.1	7.11	11/16	11/16	16.76	32.51	39.87
PMWC-06-08	3/8	1/2	21.3	7.11	7/8	11/16	16.76	38.86	43.23
PMWC-08-06	1/2	3/8	17.1	10.41	13/16	7/8	22.86	33.27	43.43
PMWC-08-08	1/2	1/2	21.3	10.41	7/8	7/8	22.86	38.86	49.02
PMWC-08-12	1/2	3/4	26.67	10.41	1-1/16	7/8	22.86	40.38	50.54
PMWC-10-08	5/8	1/2	21.3	12.7	15/16	1	24.38	38.66	49.02
PMWC-12-12	3/4	3/4	26.67	15.74	1-1/16	1-1/8	24.38	40.38	50.54
PMWC-16-16	1	1	33.4	22.35	1-3/8	1-1/2	31.24	50.03	62.23

Exceptional Pressure and Corrosion Resistance

Designed for challenging industrial settings, this connector withstands working pressures up to 6000 psi (413 bar) and provides outstanding corrosion resistance. Whether installed in oil & gas, chemical, pharmaceutical, or hydraulic systems, it ensures secure, long-term connections even in harsh environments.

Precision Engineering and Flexible Customization

Manufactured using advanced cold forming and CNC machining techniques, our connectors meet ASTM A276 and A182 standards. Options for inside diameters, wall thickness, outer diameters, and lengths allow for tailored solutions to specific project requirements, ensuring seamless system integration.

Reliable Fit for Diverse Applications

Featuring a double ferrule tube end and a male pipe weld thread (NPT/BSPT/BSP/Custom), this connector is suitable for both new installations and maintenance in instrumentation, process piping, or other specialty systems. Its robust tensile strength (minimum 515 MPa for SS 316) and high-grade surface finish offer lasting reliability and performance.

FAQs of Stainless Steel Double Ferrule Male Pipe Weld Connector:

Q: How does the double ferrule system benefit my instrumentation or process piping setup?

A: The double ferrule system provides a leak-proof seal by gripping the tubing securely without deforming it, enhancing reliability in high-pressure applications. This ensures process safety and minimizes maintenance in critical environments such as oil & gas, chemical plants, and pharmaceuticals.

Q: What customization options are available for the inside diameter and lengths of the connector?

A: We offer a full range of customizations for inside diameter, outer diameter (1/8 to 2 inches or 3 mm to 50 mm), wall thickness, and overall length, allowing you to match precise specifications for your application. You can request these customizations based on your projects unique requirements.

Q: When should I choose between NPT, BSPT, BSP, or custom thread types?

A: The selection depends on your piping standards and regional or system compatibility. NPT threads are common in North America, while BSPT/BSP are more prevalent internationally. Custom threads are available for special requirements, ensuring optimal fit within your installation.

Q: Where can this connector be used?

A: This stainless steel connector is suitable for a wide range of industries, including oil & gas, process piping, chemical, pharmaceutical, hydraulic, and instrumentation systems, particularly where high pressure and superior corrosion resistance are crucial.

Q: What processes are used in manufacturing these connectors?

A: Our connectors are produced using cold forming and CNC machining for high dimensional accuracy. They are finished with polishing, passivation, or electrolytic treatments to enhance corrosion resistance and surface smoothness, meeting stringent quality standards (ASTM A276/A182).

Q: How do the corrosion resistance and surface treatments benefit usage in harsh environments?

A: Stainless steel grades SS 304, SS 316, and SS 316L offer superior corrosion resistance, while polished, passivated, or electrolytic surface treatments add further protection. This ensures the connectors remain reliable and durable even when exposed to aggressive chemicals, high humidity, or other corrosive factors.

Q: What are the main benefits of choosing this male pipe weld connector for industrial systems?

A: The main benefits include high pressure tolerance, leak-proof double ferrule connections, exceptional durability against corrosion, flexible customization, and suitability for strict process requirements, ensuring long-term, trouble-free performance in demanding industrial environments.
