Stainless Steel Double Ferrule Bulkhead Male Connector

Price 30 INR/ Unit

Get a Price/Quote

MOQ : 25 Pieces

Stainless Steel Double Ferrule Bulkhead Male Connector Specification

Product Type
Bulkhead Male Connector

Material
Stainless Steel

Type
Double Ferrule Fitting

Technique
CNC Machined

Surface Treatment
Polished/Passivated

Standard
ASTM A276 / ASME SA276 / DIN 2353

Outer Diameter
6 mm to 25 mm

Length
Varies as per size (typically 50 mm to 120 mm)

Inside Diameter
6 mm to 25 mm (customizable)

Wall Thickness
1.5 mm to 3 mm (based on OD)

Tensile Strength
600 MPa (min)

Grade
SS304 / SS316 / SS316L

Size
1/8 to 1 (Tube OD sizes available)

Color
Silver

Stainless Steel Double Ferrule Bulkhead Male Connector Trade Information

Minimum Order Quantity
25 Pieces

FOB Port
MUMBAI

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About Stainless Steel Double Ferrule Bulkhead Male Connector

Stainless Steel Double Ferrule Bulkhead Male Connector

We are a remarkable entity, engaged in manufacturing, exporting and supplying a superior quality assortment of Bulkhead Male Connector. Available in different dimensions and other specifications, offered connector is precisely manufactured in adherence with latest industry standards with the help of cutting-edge technology using quality checked metal alloy. It is used for connecting fractional tubes in numerous mechanical and industrial applications. Besides, this Bulkhead Male Connect or can be availed from us at market leading price.

Features:

Accurate dimensions
Light weight
Easy installation
Withstand high pressure

METRIC

Part No.	Tube O.D. T mm	P (NPT)	E mm	h mm	h1 mm	H mm	F	l	l1	L	L1	Panel Hole DrillSize	Max Panel Thickness
PBMC-M06-02	6	1/8	2.28	14	17	14	17	42	26.0	51.0	35	11.60	12
PBMC-M06-04	6	1/4	4.82	14	17	14	17	47	26.0	56.0	35	11.60	12
PBMC-M10-04	10	1/4	7.11	17	19	19	18	52	29.50	60.50	38	16.40	10
PBMC-M12-04	12	1/4	10.40	22	24	22	24	60	32.0	71.0	43	19.50	1

Top IMPERIAL

Part No.	Tube O.D. T in	P (NPT)	E Min	h in	h in	H in	F	l	l1	L	L1	Panel Hole DrillSize	Max Panel Thickness
PBMC-02-02	1/8	1/8	2.28	1/2	1/2	7/16	12.70	39.87	24.63	46.48	31.24	8.33	12.70
PBMC-04-02	1/4	1/8	4.82	5/8	5/8	9/16	15.24	42.16	26.16	49.53	33.52	11.50	10.16
PBMC-04-04	1/4	1/4	4.82	5/8	5/8	9/16	15.24	45.97	26.16	53.34	33.52	11.50	10.16
PBMC-06-04	3/8	1/4	7.11	3/4	3/4	11/16	16.76	50.03	29.46	57.40	36.83	14.68	11.17
PBMC-08-06	1/2	3/8	9.39	15/16	15/16	7/8	22.86	53.08	31.75	63.24	41.91	19.44	12.70
PBMC-08-08	1/2	1/2	10.41	15/16	15/16	7/8	22.86	58.67	31.75	68.83	41.91	19.44	12.70

Engineered for Performance and Reliability

This double ferrule bulkhead male connector is meticulously constructed using high-quality stainless steel, ensuring superior corrosion resistance and strength. Its double ferrule mechanism provides secure tube grip and leak-proof performance even under high pressure, making it trusted for instrumentation and fluid transfer applications in challenging environments.

Versatile Connections and Broad Compatibility

Available in multiple thread types (NPT, BSPT, BSP) and sizes, this fitting supports a wide range of tubing materials like stainless steel, copper, nylon, and PTFE. Its panel mount bulkhead design allows for easy and precise integration into control panels and enclosures, while the customizable dimensions cater to varied installation needs.

FAQs of Stainless Steel Double Ferrule Bulkhead Male Connector:

Q: How is the Stainless Steel Double Ferrule Bulkhead Male Connector typically installed?

A: This connector is designed for panel mounting. To install, you pass the connector through a panel hole and secure it with the provided nut. Then, the tube is inserted, and the double ferrule system is tightened to ensure a leak-proof and secure connection.

Q: What applications are best suited for this double ferrule fitting?

A: Its ideal for instrumentation, hydraulic, and pneumatic systems, particularly where robust, leak-free connections are vital. Its high-pressure rating and compatibility with gases, oils, water, and chemical fluids make it suitable for a range of industrial and process control environments.

Q: When should I choose this bulkhead connector over other fittings?

A: Select this fitting when you require a panel-mounted, corrosion-resistant connector that provides secure connections at pressures up to 6000 psi. It is particularly recommended when precise, maintenance-free performance is essential in harsh or critical fluid service conditions.

Q: Where can this connector be used regarding tube and thread compatibility?

A: The connector supports outer tube diameters from 6 mm to 25 mm, or 1/8 to 1 OD, and accepts NPT, BSPT, or BSP male threads. It can be used with stainless steel, copper, nylon, or PTFE tubing, fitting a wide range of installation scenarios.

Q: What is the best process for ensuring a reliable, leak-proof seal with this connector?

A: To achieve a leak-proof seal, insert the tube fully into the connector, then tighten the nut to compress the double ferrules onto the tube. For best results, follow the manufacturers installation guidelines and use tubes with proper wall thickness and surface finish.

Q: How does the double ferrule design benefit my system?

A: The double ferrule system delivers consistent sealing through two-stage tube gripping, minimizing the risk of leaks even under vibration or high pressure. This design offers prolonged service life, simple maintenance, and outstanding reliability in demanding environments.
