Stainless Steel Flare Union Cross

Get a Price/Quote

Stainless Steel Flare Union Cross Specification

Application
Hydraulic, Pneumatic, Gas, Oil & Chemical Fittings

Packaging
Carton / Wooden Box

Temperature Range
-40°C to +300°C

Thread Standard
NPT, BSP, UNF

Maximum Working Pressure
Up to 6000 PSI

Usage
Industrial Fluid Transmission

Finish Type
Mirror / Satin

Corrosion Resistance
Excellent

Weight
Variable as per size

Connection Type
Flare Threaded

About Stainless Steel Flare Union Cross

Stainless Steel Flare Union Cross

We, Pioneer Industries, are affianced in manufacturing, exporting and supplying PUC Union cross. Offered cross is manufactured using premium quality stainless steel with help of latest techniques at our advanced production unit under deft professionals guidance. Provided cross is specially used for in plumbing application to connect four pipe together. Apart from this, our valuable client can avail the PUC Union cross from us at rock bottom prices.

Feature:

High durability
Accurate dimension
Non corrosive
Supreme finish

METRIC

Part No.	Tube O.D. T mm	E mm	h mm	H mm	F	G	l	L
MPUC-03	3	2.4	9.5	12	12.9	15.3	15.7	22.3
MPUC-06	6	4.8	12.7	14	15.3	17.7	19.6	27.0
MPUC-08	8	6.4	14.3	16	16.2	18.6	21.3	28.8
MPUC-10	10	7.9	17.5	19	17.2	19.5	23.9	31.5
MPUC-12	12	9.5	20.6	22	22.8	22.0	25.9	36.0
MPUC-16	16	12.7	25.4	25	24.4	22.0	28.7	38.8
MPUC-18	18	15.1	27.0	30	24.4	22.0	29.7	39.8
MPUC-20	20	15.9	31.8	32	26.0	22.0	32.5	42.6
MPUC-25	25	21.8	36.0	38	31.3	22.0	36.8	49.1

IMPERIAL

Part No.	Tube O.D. T in	E Min	h in	H in	F	G	l	L
IPUC-01	1/16	1.27	3/8	5/16	8.63	10.91	14.00	25.15
IPUC-02	1/8	2.28	3/8	7/16	12.70	15.24	15.74	35.56
IPUC-03	3/16	3.04	1/2	1/2	13.71	16.00	17.78	37.33
IPUC-04	1/4	4.82	1/2	9/16	15.24	17.78	19.55	40.89
IPUC-05	5/16	6.35	1/2	5/8	16.25	18.54	21.33	42.92
IPUC-06	3/8	7.11	11/16	11/16	16.76	19.30	23.11	44.95
IPUC-08	1/2	10.41	13/16	7/8	22.86	21.84	25.90	51.30
IPUC-10	5/8	12.70	13/16	1	24.38	21.84	28.70	52.07
IPUC-12	3/4	15.74	1	1-1/8	24.38	21.84	29.71	53.59
IPUC-14	7/8	18.28	1-1/4	1-1/4	25.90	21.84	34.54	55.37
IPUC-16	1	22.35	1-27/64	1-1/2	31.24	26.41	36.83	64.77
