5 Valve Manifold - Pipe to Flange

Get a Price/Quote

5 Valve Manifold - Pipe to Flange Specification

Handle Type
Round or T-bar

Number of Valves
5 (two isolation, two equalizing, one bleed)

Weight
Varies with model and material, typically 3-7 kg

Surface Finish
Electropolished/machined

Color
Silver (natural metal finish)

Standards Compliance
ASME B16.5 for flanges, NACE MR0175 for sour service

Maintenance
Field-replaceable parts, easy servicing

Packing
PTFE/Graphite

Test & Certification
Hydrostatic and pneumatic tested as per industry standards

Leakage Rate
Bubble tight shut off

Flange Standard
IEC/DIN, ANSI, or customized

Mounting
Direct mounting to transmitter or impulse lines

Torque Value
Factory preset or adjustable

End Connection Material
As per body material

Bonnet Type
Screwed bonnet with non-rotating spindle

5 Valve Manifold - Pipe to Flange Trade Information

Supply Ability

Delivery Time
7 Days

Main Domestic Market
All India

About 5 Valve Manifold - Pipe to Flange

Made of stainless steel (316/304 grade), this 5 Valve Manifold - Pipe to Flange is suitable for high temperature and high pressure based applications. This manually controlled valve has maximum 1 inch port size and up to6mm dimension. This valve features female thread and it has global certification. Provided 5 Valve Manifold - Pipe to Flange is suitable for transferring gas, oil and water. This accessory can endure 6000 PSI operating pressure. Ergonomic appearance, high strength and reasonable price are its key aspects.
