Send InquiryStainless Steel Single Ferrule Union
Price 150 INR/ Unit
MOQ : 1 , , Unit
Stainless Steel Single Ferrule Union Specification
- End Type
- Double Ferrule
- Connection Method
- Threaded / Welded
- Corrosion Resistance
- Excellent
- Packaging Type
- Box / Carton
- Application
- Chemical, Gas, Oil, Hydraulic, Instrumentation
- Pressure Rating
- Up to 6000 PSI
- Temperature Range
- -20°C to 450°C
About Stainless Steel Single Ferrule Union
Stainless Steel Single Ferrule Union
| Part No. | Tube O.D. T mm |
E mm |
h mm | H mm | F | G | l | L |
|---|---|---|---|---|---|---|---|---|
| MPU - M 02 | 2 | 1.7 | 12 | 12 | 12.9 | 15.3 | 22.4 | 35.6 |
| MPU - M 03 | 3 | 2.4 | 12 | 12 | 12.9 | 15.3 | 22.1 | 35.3 |
| MPU - M 04 | 4 | 2.4 | 12 | 12 | 13.7 | 16.1 | 24.1 | 37.3 |
| MPU - M 06 | 6 | 4.8 | 14 | 14 | 15.3 | 17.7 | 26.2 | 41.0 |
| MPU - M 08 | 8 | 6.4 | 15 | 16 | 16.2 | 18.6 | 28.2 | 43.2 |
| MPU - M 10 | 10 | 7.9 | 18 | 19 | 17.2 | 19.5 | 31.0 | 46.2 |
| MPU - M 12 | 12 | 9.5 | 22 | 22 | 22.8 | 22.0 | 31.0 | 51.2 |
| MPU - M 15 | 15 | 11.9 | 24 | 25 | 24.4 | 22.0 | 31.8 | 52.0 |
| MPU - M 20 | 20 | 15.9 | 30 | 32 | 26.0 | 22.0 | 34.8 | 55.0 |
| MPU - M 22 | 22 | 18.3 | 30 | 32 | 26.0 | 22.0 | 34.8 | 55.0 |
| MPU - M 25 | 25 | 21.8 | 35 | 38 | 31.3 | 26.5 | 40.4 | 65.0 |
