Stainless Steel Single Ferrule Reducer

Price 200 INR/ Unit

Get a Price/Quote

MOQ : 50 Units

Stainless Steel Single Ferrule Reducer Specification

Packaging Type
Box / Polybag

Operating Pressure
Up to 6000 psi

End Connection
Tube OD x Tube OD Reducer

Rust Proof
Yes

Corrosion Resistance
Excellent

Leakproof
Yes

Usage
Instrumentation, Industrial, Hydraulic Pipe Fittings

Temperature Range
-54°C to +204°C

Connection Type
Single Ferrule Compression

Finish
Bright Finish

Stainless Steel Single Ferrule Reducer Trade Information

Minimum Order Quantity
50 Units

Delivery Time
2 Week

About Stainless Steel Single Ferrule Reducer

Stainless Steel Single Ferrule Reducer

Being a quality conscious enterprise, we are engaged in manufacturing, exporting and supplying a flawless range of PR Reducer. This reducer is manufactured under the supervision of our diligent professionals with the use of best quality raw materials and advanced techniques as per industrial standards. The provided reducer finds usage in pipe fitting and fluid passage applications. Besides, our clients can purchase the offered PR Reducer at competitive prices from us.

Features:

Smooth finish
Long life
High strength
Rust free nature

METRIC

Part No.	Tube O.D.		E mm	h mm	H mm	F	G	l	L
Part No.	T mm	T1mm	E mm	h mm	H mm	F	G	l	L
MPR-03-04	3	4	2.4	12	12	12.9	15.3	28.4	35.0
MPR-03-06	3	6	2.4	12	12	12.9	15.3	29.5	36.1
MPR-03-10	3	10	2.4	12	12	12.9	15.3	31.8	38.4
MPR-04-06	4	6	2.4	12	12	13.7	16.1	30.5	37.1
MPR-06-03	6	3	1.8	14	14	15.3	17.7	29.5	36.9
MPR-06-08	6	8	4.8	14	14	15.3	17.7	32.5	39.9
MPR-06-10	6	10	4.8	14	14	15.3	17.7	33.3	40.7
MPR-06-12	6	12	4.8	14	14	15.3	17.7	28.9	46.3
MPR-08-06	8	6	4.6	15	16	16.2	18.6	32.8	40.3
MPR-08-10	8	10	6.4	15	16	16.2	18.6	34.5	42.0
MPR-08-12	8	12	6.4	15	16	16.2	18.6	40.1	47.6
MPR-10-06	10	6	4.6	18	19	17.2	19.5	34.8	42.4
MPR-10-12	10	12	7.9	18	19	17.2	19.5	42.2	49.8
MPR-10-15	10	15	7.9	18	19	17.2	19.5	43.7	51.3
MPR-10-18	10	18	7.9	19	19	17.2	19.5	43.7	51.3
MPR-12-06	12	6	4.6	22	22	22.8	22.0	34.8	44.9
MPR-12-10	12	10	7.7	22	22	22.8	22.0	36.6	46.7
MPR-12-16	12	16	9.5	22	22	22.8	22.0	43.7	53.8
MPR-12-18	12	18	9.5	22	22	22.8	22.0	43.7	53.8
MPR-12-20	12	20	9.5	22	22	22.8	22.0	46.0	56.1
MPR-12-22	12	22	9.5	24	22	22.8	22.0	46.0	56.1
MPR-12-25	12	25	9.5	27	22	22.8	22.0	52.3	62.4
MPR-16-12	16	12	9.1	24	25	24.4	22.0	42.9	53.0
MPR-18-12	18	12	9.1	27	30	24.4	22.0	44.5	54.6
MPR-18-16	18	16	12.7	27	30	24.4	22.0	46.0	56.1

IMPERIAL

Part No.	Tube O.D.		E Min	h in	H in	F	G	l	L
Part No.	T in	T1 in	E Min	h in	H in	F	G	l	L
IPR-02-01	1/8	1/16	0.76	7/16	7/16	12.70	15.24	22.35	28.95
IPR-02-02	1/8	1/8	2.03	7/16	7/16	12.70	15.24	26.92	33.52
IPR-02-03	1/8	3/16	2.28	7/16	7/16	12.70	15.24	27.68	34.29
IPR-02-04	1/8	1/4	2.28	7/16	7/16	12.70	15.24	29.46	36.06
IPR-02-06	1/8	3/8	2.28	7/16	7/16	12.70	15.24	30.98	37.59
IPR-02-08	1/8	1/2	2.28	9/16	7/16	12.70	15.24	37.59	44.19
IPR-03-02	3/16	1/8	2.03	7/16	1/2	13.71	16.00	28.90	34.79
IPR-03-04	3/16	1/4	3.04	7/16	1/2	13.71	16.00	30.48	37.08
IPR-04-02	1/4	1/8	2.03	1/2	9/16	15.24	17.78	29.46	36.83
IPR-04-03	1/4	3/16	3.04	1/2	9/16	15.24	17.78	30.22	37.59
IPR-04-04	1/4	1/4	4.82	1/2	9/16	15.24	17.78	31.75	39.11
IPR-04-05	1/4	5/16	4.82	1/2	9/16	15.24	17.78	32.51	39.87
IPR-04-06	1/4	3/8	4.82	1/2	9/16	15.24	17.78	33.27	40.64
IPR-04-08	1/4	1/2	4.82	9/16	9/16	15.24	17.78	38.86	46.22
IPR-04-10	1/4	5/8	4.82	11/16	9/16	15.24	17.78	40.64	48.00
IPR-04-12	1/4	3/4	4.82	13/16	9/16	15.24	17.78	40.38	47.75
IPR-05-06	5/16	3/8	6.35	9/16	5/8	16.25	18.54	34.54	41.91
IPR-05-08	5/16	1/2	6.35	9/16	5/8	16.25	18.54	40.13	47.49
IPR-06-04	3/8	1/4	4.82	5/8	11/16	16.76	19.30	34.03	41.40
IPR-06-06	3/8	3/8	7.11	5/8	11/16	16.76	19.30	35.81	43.18
IPR-06-08	3/8	1/2	7.11	5/8	11/16	16.76	19.30	41.14	48.51
IPR-06-10	3/8	5/8	7.11	11/16	11/16	16.76	19.30	42.92	50.29
IPR-06-12	3/8	3/4	7.11	13/16	11/16	16.76	19.30	42.92	50.29
IPR-08-04	1/2	1/4	4.82	13/16	7/8	22.86	21.84	34.79	44.95
IPR-08-06	1/2	3/8	7.11	13/16	7/8	22.86	21.84	36.57	46.73
IPR-08-08	1/2	1/2	9.90	13/16	7/8	22.86	21.84	42.16	52.32
IPR-08-10	1/2	5/8	10.41	13/16	7/8	22.86	21.84	43.68	53.84
IPR-08-12	1/2	3/4	10.41	13/16	7/8	22.86	21.84	43.68	53.84
IPR-08-16	1/2	1	10.41	1-1/16	7/8	22.86	21.84	50.03	60.19
IPR-10-12	5/8	3/4	12.70	15/16	1	24.38	21.84	44.45	54.61
IPR-10-14	5/8	7/8	12.70	15/16	1	24.38	21.84	45.97	56.13
IPR-10-16	5/8	1	12.70	1-1/16	1	24.38	21.84	50.80	60.96
IPR-12-08	3/4	1/2	9.90	1-1/16	1-1/8	24.38	21.84	44.45	54.61
IPR-12-16	3/4	1	15.74	1-1/16	1-1/8	24.38	21.84	52.32	62.48
