Stainless Steel Flare Elbow Union

Get a Price/Quote

Stainless Steel Flare Elbow Union Specification

Corrosion Resistance
High

Packaging Type
Box / Carton

Temperature Range
-50°C to 300°C

Connection Type
Flare Threaded Union

Finish
Bright Polished

Pressure Rating
Up to 6000 PSI

Installation
Easy to Install, Leak Proof Joint

Usage/Application
Hydraulic, Pneumatic, Gas, Water Systems

About Stainless Steel Flare Elbow Union

Stainless Steel Flare Elbow Union

We are successfully engaged in manufacturing, exporting and supplying the best quality PEU Elbow Union that is available in different specifications. This union is manufactured using supreme grade raw materials with the aid of innovative technique as per set industry standards. The offered union is used for gas plumbing application. Moreover, the provided PEU Elbow Union can be availed at affordable prices from us.

Feature:

Sturdy design
Rust proof
Accurate dimension
Easy to use

METRIC

Part No.	Tube O.D. T mm	E mm	h mm	H mm	F	G	l	L
MPEU - 02	2	1.7	9.5	12	12.9	15.3	15.7	22.3
MPEU - 03	3	2.4	9.5	12	12.9	15.3	15.7	22.3
MPEU - 04	4	2.4	12.7	12	13.7	16.4	18.8	25.4
MPEU - 06	6	4.8	12.7	14	15.3	17.7	19.6	27.0
MPEU - 08	8	6.4	14.3	16	16.2	18.6	21.3	28.8
MPEU - 10	10	7.9	17.5	19	17.2	19.5	23.9	31.5
MPEU - 12	12	9.5	20.6	22	22.8	22.0	25.9	36.0
MPEU - 15	15	11.9	25.4	25	24.4	22.0	28.7	38.8
MPEU - 16	16	12.7	25.4	25	24.4	22.0	28.7	38.8
MPEU - 18	18	15.1	27.0	30	24.4	22.0	29.7	39.8
MPEU - 20	20	15.9	31.8	32	26.0	22.0	32.5	42.6
MPEU - 22	22	18.3	31.8	32	26.0	22.0	32.5	42.6
MPEU - 25	25	21.8	36.0	38	31.3	26.5	36.8	49.1

IMPERIAL

Part No.	Tube O.D. T in	E Min	h in	H in	F	G	l	L
IPEU-01	1/16	1.27	3/8	5/16	8.63	10.92	14.00	17.88
IPEU-02	1/8	2.28	3/8	7/16	12.70	15.24	15.74	22.35
IPEU-03	3/16	3.04	1/2	1/2	13.71	16.00	17.78	24.38
IPEU-04	1/4	4.82	1/2	9/16	15.24	17.78	19.55	26.92
IPEU-05	5/16	6.35	9/16	5/8	16.25	18.54	21.33	28.70
IPEU-06	3/8	7.11	5/8	11/16	16.76	19.30	23.11	30.48
IPEU-08	1/2	10.41	13/16	7/8	22.86	21.84	25.90	36.06
IPEU-10	5/8	12.70	15/16	1	24.38	21.84	28.70	38.80
IPEU-12	3/4	15.74	1-1/16	1-1/8	24.38	21.84	29.71	39.87
IPEU-14	7/8	18.28	1-1/4	1-1/4	25.90	21.84	34.54	44.70
IPEU-16	1	22.35	1-27/64	1-1/2	31.24	26.41	36.83	49.02
